Rigid MC Metal Core PCB Printed Circuit Board For Car Electronics

Name: Rigid MC Metal Core PCB Printed Circuit Board For Car Electronics
Brand: Shenzhen Tecircuit Electronics Limited
SKU: TEC0146
Price: 5.99 USD
Availability: InStock

Brand Name:	TECircuit
Model Number:	TEC0146
MOQ:	1pcs
Price:	USD 1.99 ~ USD9.99/pcs
Delivery Time:	5-15 wotk days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

UL,ISO 9001, ISO 14001, ISO 13485, ITAF 16949, ROHS,REACH. W

Brand:

Shenzhen Tecircuit Electronics Co., Ltd

Product Type:

PCB,High Frequency Board,RIGID PCB,Rigid Board,Flexible Board,Rigid-Flex PCB,IC-Substrate,Metal Core

Item No.:

R0049

Service:

PCBA Service

Packaging Details:

Vacuum package+Carton box

Supply Ability:

50000 pcs/month

Highlight:

Car Electronics Metal Core PCB

Car Electronics Printed Circuit Board

Rigid MC Metal Core PCB

Product Description

Product Images

About TECircuit

Found: TECircuit has been operating since 2004.

Location: An electronics manufacturing service(EMS) provider located in Shenzhen China.

Item: Customizable EMS PCB, offers a full range of one-stop shop services.

Service: Printed Circuit Board (PCB)and Printed Circuit Board Assembly(PCBA), Flexible Printed Circuit Board(FPC), Components Sourcing, Box-Building, Testing.

Quality Assurance: UL,ISO 9001, ISO 14001, ISO 13485, ITAF 16949 andcomplied with ROHS and REACH.

Factory Pictures:
Company's own plant : 50,000 sqm; Employees : 930+; Monthly production capacity : 100,000 m2

Product Applications

Infotainment Systems:
- Used in car audio and multimedia systems to convert and manage power efficiently for various components, including displays and amplifiers.
Navigation Systems:
- Employed in GPS and navigation devices, ensuring stable power delivery for accurate positioning and functionality.
Battery Management Systems (BMS):
- Integrated into systems that monitor and manage battery performance, particularly in electric and hybrid vehicles.
Lighting Control:
- Used in automotive lighting systems, including LED headlights, taillights, and interior lighting, to manage power efficiently.
Climate Control Systems:
- Employed in heating, ventilation, and air conditioning (HVAC) systems for efficient power distribution to fans and compressors.
Safety Systems:
- Integrated into systems like airbags, anti-lock braking systems (ABS), and electronic stability control (ESC), where reliable power is crucial.
Power Distribution Units (PDUs):
- Used in central power distribution systems within vehicles to manage power supply to various electronic components.
Sensor Systems:
- Employed in automotive sensors for monitoring tire pressure, temperature, and other critical parameters, ensuring efficient power management.
Electric Vehicle (EV) Systems:
- Used in power inverters and converters for electric and hybrid vehicles, facilitating efficient energy conversion and management.
Telematics:
- Integrated into telematics systems for vehicle tracking, diagnostics, and communication, requiring stable and reliable power sources.

Product Features

High Thermal Conductivity:
- Aluminum PCBs effectively dissipate heat generated by power components, ensuring reliable operation in automotive environments.
Durability:
- The robust aluminum substrate can withstand harsh conditions, including vibrations, temperature fluctuations, and moisture.
Low Coefficient of Thermal Expansion (CTE):
- The CTE of aluminum is compatible with many electronic components, reducing thermal stress and enhancing reliability.
Electrical Insulation:
- Provides excellent electrical insulation properties, ensuring safe operation in high-voltage automotive applications.
Compact Design:
- Allows for thinner and lighter designs, which is advantageous in space-constrained automotive environments.
High Reliability:
- Offers long-term stability and durability, crucial for automotive applications that demand consistent performance.
Customizability:
- Can be tailored to specific design requirements, including layout, thickness, and surface finish to suit various automotive needs.
Ease of Manufacturing:
- Compatible with standard PCB manufacturing processes, facilitating efficient production and assembly.
Cost-Effectiveness:
- Although generally more expensive than traditional FR4 PCBs, the benefits in thermal management and reliability often justify the investment.
Regulatory Compliance:
- Designed to meet automotive industry standards for safety and performance, ensuring reliable operation in diverse automotive applications.

FAQ

Question 1: What is needed for a quotation?
Answer:
PCB: QTY, Gerber file, and Technical Requirements( material/surface finish treatment/copper thickness/board thickness,...)
PCBA: PCB information, BOM,(Testing documents...)

Q2: What file formats do you accept for production?
Answer:
PCB Gerber file
BOM list for PCB
Test method for PCBA

Q3: Are my files safe?
Answer:
Your files are held completely safe and secure. We protect the IP for our customers in the whole process. All documents from customers are never shared with any 3rd parties.

Q4: What is the shipment method?
Answer:
We can offer FedEx /DHL / TNT / UPS for shipment. Also, customer provided shipment method is acceptable.

Q5: What is the payment method?
Answer:
Telegraphic Transfer in advance (Advance TT, T/T), PayPal is acceptable.

Product Description

Specification:
PCB layers:	1-42layers
PCB materials:	CEM1, CEM3, Rogers, FR-4, High Tg FR-4, Aluminum Base, Halogen Free
PCB max. board size:	620mm*1100mm
PCB certificate:	RoHS Directive-Compliant
PCB Thickness:	1.6 ±0.1mm
Out Layer Copper Thickness:	0.5-5oz
Inner Layer Copper Thickness:	0.5-4oz
PCB max. board thickness:	6.0mm
Minimum Hole Size:	0.20mm
Minimum Line Width/Space:	3/3mil
Min. S/M Pitch:	0.1mm(4mil)
Plate Thickness and Aperture Ratio :	30:1
Minimum Hole Copper:	20µm
Hole Dia. Tolerance(PTH):	±0.075mm(3mil)
Hole dia. Tolerance(NPTH):	±0.05mm (2mil)
Hole Position Deviation:	±0.05mm (2mil)
Outline Tolerance:	±0.05mm (2mil)
PCB solder mask:	Black, white, yellow
PCB surface finished:	HASL Leadfree,Immersion ENIG,Chem Tin,Flash Gold,OSP,Gold finger,Peelable,Immersion Silver
Legend:	White
E-test:	100% AOI, X-ray, Flying probe test.
Outline:	Rout and Score/V-cut
Inspection Standard:	IPC-A-610CCLASSII
Certificates:	UL (E503048),ISO9001/ISO14001/IATF16949
Outgoing Reports:	Final Inspection, E-test, Solderability Test, Micro Section and More
