Metal Core PCB Printed Circuit Board Manufacturing For Communication Base Station

Name: Metal Core PCB Printed Circuit Board Manufacturing For Communication Base Station
Brand: Shenzhen Tecircuit Electronics Limited
SKU: TEC0141
Price: 5.99 USD
Availability: InStock

Brand Name:	TECircuit
Model Number:	TEC0141
MOQ:	1pcs
Price:	USD 1.99 ~ USD9.99/pcs
Delivery Time:	5-15 wotk days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

UL,ISO 9001, ISO 14001, ISO 13485, ITAF 16949, ROHS,REACH. W

Brand:

Shenzhen Tecircuit Electronics Co., Ltd

Product Type:

PCB,High Frequency Board,RIGID PCB,Rigid Board,Flexible Board,Rigid-Flex PCB,IC-Substrate,Metal Core

Item No.:

R0045

Service:

PCBA Service

Packaging Details:

Vacuum package+Carton box

Supply Ability:

50000 pcs/month

Highlight:

Communication Metal Core PCB Manufacturing

Communication Base Station Metal Core PCB

Product Description

Product Images

About TECircuit

Found: TECircuit has been operating since 2004.

Location: An electronics manufacturing service(EMS) provider located in Shenzhen China.

Item: Customizable EMS PCB, offers a full range of one-stop shop services.

Service: Printed Circuit Board (PCB)and Printed Circuit Board Assembly(PCBA), Flexible Printed Circuit Board(FPC), Components Sourcing, Box-Building, Testing.

Quality Assurance: UL,ISO 9001, ISO 14001, ISO 13485, ITAF 16949 andcomplied with ROHS and REACH.

Factory Pictures:
Company's own plant : 50,000 sqm; Employees : 930+; Monthly production capacity : 100,000 m2

Product Applications

Power Supply Units (PSUs):
- Used in both AC-DC and DC-DC converters to handle high power levels efficiently and maintain thermal stability.
LED Drivers:
- Employed in LED lighting applications to manage power delivery while ensuring effective heat dissipation for long-lasting performance.
Automotive Electronics:
- Integrated into power management systems in electric and hybrid vehicles, ensuring reliable operation under varying conditions.
Telecommunications Equipment:
- Used in RF amplifiers, base stations, and other telecom devices where efficient power management is critical.
Industrial Control Systems:
- Employed in automation equipment and machinery control boards, where high reliability and thermal management are essential.
Medical Devices:
- Integrated into diagnostic and therapeutic equipment, providing stable and efficient power delivery to sensitive components.
Consumer Electronics:
- Used in devices like gaming consoles, home appliances, and audio equipment, where reliable power management is crucial.
Renewable Energy Systems:
- Employed in solar inverters and wind turbine controllers, facilitating efficient power conversion and management.
Battery Management Systems:
- Used in systems that monitor and control battery charging and discharging, ensuring safe and efficient operation.
Heating Elements:
- Integrated into applications that require precise temperature control, such as electric heaters and heat guns.

Product Features

High Thermal Conductivity:
- Aluminum PCBs provide excellent heat dissipation, critical for maintaining the performance of high-power components.
Durability:
- The robust aluminum substrate can withstand mechanical stress, making it suitable for demanding environments.
Low Coefficient of Thermal Expansion (CTE):
- The CTE of aluminum closely matches that of electronic components, reducing thermal stress and enhancing reliability.
Electrical Insulation:
- Provides excellent electrical insulation, ensuring safe operation in high-power applications.
Compact Design:
- Allows for thinner and lighter designs, which is beneficial in space-constrained applications.
High Reliability:
- Offers long-term stability and durability, essential for critical applications in various industries.
Customizability:
- Can be tailored to specific design requirements, including thickness, layout, and surface finish.
Ease of Manufacturing:
- Compatible with standard PCB manufacturing processes, allowing for efficient production and assembly.
Cost-Effective:
- While generally more expensive than traditional FR4 PCBs, the long-term benefits in thermal management and reliability often justify the investment.
Regulatory Compliance:
- Designed to meet industry standards for safety and performance, ensuring reliable operation in various applications.

FAQ

Question 1: What is needed for a quotation?
Answer:
PCB: QTY, Gerber file, and Technical Requirements( material/surface finish treatment/copper thickness/board thickness,...)
PCBA: PCB information, BOM,(Testing documents...)

Q2: What file formats do you accept for production?
Answer:
PCB Gerber file
BOM list for PCB
Test method for PCBA

Q3: Are my files safe?
Answer:
Your files are held completely safe and secure. We protect the IP for our customers in the whole process. All documents from customers are never shared with any 3rd parties.

Q4: What is the shipment method?
Answer:
We can offer FedEx /DHL / TNT / UPS for shipment. Also, customer provided shipment method is acceptable.

Q5: What is the payment method?
Answer:
Telegraphic Transfer in advance (Advance TT, T/T), PayPal is acceptable.

Product Description

Specification:
PCB layers:	1-42layers
PCB materials:	CEM1, CEM3, Rogers, FR-4, High Tg FR-4, Aluminum Base, Halogen Free
PCB max. board size:	620mm*1100mm
PCB certificate:	RoHS Directive-Compliant
PCB Thickness:	1.6 ±0.1mm
Out Layer Copper Thickness:	0.5-5oz
Inner Layer Copper Thickness:	0.5-4oz
PCB max. board thickness:	6.0mm
Minimum Hole Size:	0.20mm
Minimum Line Width/Space:	3/3mil
Min. S/M Pitch:	0.1mm(4mil)
Plate Thickness and Aperture Ratio :	30:1
Minimum Hole Copper:	20µm
Hole Dia. Tolerance(PTH):	±0.075mm(3mil)
Hole dia. Tolerance(NPTH):	±0.05mm (2mil)
Hole Position Deviation:	±0.05mm (2mil)
Outline Tolerance:	±0.05mm (2mil)
PCB solder mask:	Black, white, yellow
PCB surface finished:	HASL Leadfree,Immersion ENIG,Chem Tin,Flash Gold,OSP,Gold finger,Peelable,Immersion Silver
Legend:	White
E-test:	100% AOI, X-ray, Flying probe test.
Outline:	Rout and Score/V-cut
Inspection Standard:	IPC-A-610CCLASSII
Certificates:	UL (E503048),ISO9001/ISO14001/IATF16949
Outgoing Reports:	Final Inspection, E-test, Solderability Test, Micro Section and More
